xcluma Mini type-c charging bank motherboard lithium charge module battery boost 3.1A output

Price: ₹529 - ₹376.00
(as of Dec 13, 2025 15:44:00 UTC – Details)


Product Description

• Support PD3.0/PD2.0 voltage decoy output and free mode switching.
  Support 5V/9V/12V/15V/20V decoy output (specific range depends on your power supply).
• With key lock function to prevent misoperation (to avoid damage to load equipment due to mis-setting voltage.
• 5V/9V/12V/20V fast setting. LED indicates output.
• The parameter braking is saved, and the last trick setting is executed by powering on again.
  Ultra-low power consumption (slightly heated at 20V), supporting 100W output.
• Maximum 20V5A output (actual value depends on your power supply).
• The type c male head is integrally formed and durable.

How to use:
1. Press and hold the S key, then insert the module into the power supply, and then reset to 5V output (“>>” means power on)
2. Press and hold the S+key, and then insert the module into the power supply. At this time, switch whether the key lock is turned on and the status is saved when the power is turned on. If the key lock is turned on, the voltage can be adjusted only after the power is turned on to prevent misoperation.
3. After power-on, press and hold S+and then press S – to unlock when there is a key lock.
4. After power on, press and hold S – and then press S+to lock the key.
Quick start: plug the board into the PD power supply. At this time, the LED light indicates the existing set decoy voltage. If it is not on, it means the default 5V. If you want to adjust the output voltage. The board is locked by default. At this time, you need to unlock it first. The method is to press and hold S+, and then press S -. At this time, the unlocking is completed, and you can release the key. Then click S+to increase the voltage or click S – to decrease the voltage.

Support PD3.0/PD2.0 voltage decoy output and free mode switching.
TYPE-C interface is integrally formed, durable
The touch of keys is good and the height is appropriate.
The original chip is used, with excellent workmanship
Product Contents:1x xcluma Mini type-c charging bank motherboard lithium charge module battery boost 3.1A output
